Optical

Optical wavelength

nm

1310 or 1550

Optical Input power range

mw

+1.5- -7

Optical connector type

SC/APC

Others on request

C/N

dB

51

Connected with standard optical transmitter, tested at predicted optical link loss, OMI of optical transmitter 3.6%;loaded 59 PAL-D analogue TV channels, and 33 QAM64 digital CW; the level of digital CW lower 6dB than analogue’s

CTB

dBc

5

CSO

dBc

60

RF

Bandwidth

MHz

47/87~750/862

Flatness

dB

±1.5

RF Return Loss

dB

＜-16

@550MHz

dB

＜-14

@862MHz

RF output level

dBuV

112

@optical Input power -2dBm, and flat output

DFB

FP

RFInput Level

dBmV

35

35

Output Optical Power

mw

1~4

＞1

Input Return Loss

dB

<-16

<-16

Flatness

dB

±1,(5~200MHz)

±1,(5~200MHz)

C/N

dB

＞50

＞45

1)Four Signals Test:19.25.31.37MHz

2)Two Signal Test: 13，19MHz

3)Test Condition: standard optical receiver, 10dB optical link loss.

CSO

dBc

＜-51

＜-45

CTB

dBc

＜-55

＜-45

Optical Wavelength

nm

1310

1310

Work Temperature

℃

-20~+85

-20~+85
